| Designation | Mass per Metre | Depth of Section h |
Width of Section b |
Thickness Web s |
Thickness Flange t |
Root Radius r |
Depth between fillets d |
Ratios for Local Buckling | |
| kg/m | mm | mm | mm | mm | mm | mm | Flange b/2t | Web d/s | |
| 356 x 368 x 174 | 173.9 | 361.4 | 378.5 | 20.3 | 20.4 | 15.2 | 290.2 | 9.28 | 14.3 |
| 356 x 368 x 152 | 152.0 | 356.4 | 376.0 | 17.8 | 17.9 | 15.2 | 290.2 | 10.5 | 16.3 |
| 356 x 368 x 133 | 133.0 | 352.0 | 373.8 | 15.6 | 15.7 | 15.2 | 290.2 | 11.9 | 18.6 |
| 356 x 368 x 109 | 108.9 | 346.4 | 371.0 | 12.8 | 12.9 | 15.2 | 290.2 | 14.4 | 22.7 |
| 305 x 305 x 223 | 222.9 | 337.9 | 325.7 | 30.3 | 30.4 | 15.2 | 246.7 | 5.36 | 8.14 |
| 305 x 305 x 186 | 186.0 | 328.3 | 320.9 | 25.5 | 25.6 | 15.2 | 246.7 | 6.27 | 9.67 |
| 305 x 305 x 149 | 149.1 | 318.5 | 316.0 | 20.6 | 20.7 | 15.2 | 246.7 | 7.63 | 12.0 |
| 305 x 305 x 126 | 126.1 | 312.3 | 312.9 | 17.5 | 17.6 | 15.2 | 246.7 | 8.89 | 14.1 |
| 305 x 305 x 110 | 110.0 | 307.9 | 310.7 | 15.3 | 15.4 | 15.2 | 246.7 | 10.1 | 16.1 |
| 305 x 305 x 95 | 94.9 | 303.7 | 308.7 | 13.3 | 13.3 | 15.2 | 246.7 | 11.6 | 18.5 |
| 305 x 305 x 88 | 88.0 | 301.7 | 307.8 | 12.4 | 12.3 | 15.2 | 246.7 | 12.5 | 19.9 |
| 305 x 305 x 79 | 78.9 | 299.3 | 306.4 | 11.0 | 11.1 | 15.2 | 246.7 | 13.8 | 22.4 |
| 254 x 254 x 85 | 85.1 | 254.3 | 260.4 | 14.4 | 14.3 | 12.7 | 200.3 | 9.10 | 13.9 |
| 254 x 254 x 71 | 71.0 | 249.7 | 258.0 | 12.0 | 12.0 | 12.7 | 200.3 | 10.8 | 16.7 |
| 254 x 254 x 63 | 63.0 | 247.1 | 256.6 | 10.6 | 10.7 | 12.7 | 200.3 | 12.0 | 18.9 |
| 203 x 203 x 54 | 53.9 | 204.0 | 207.7 | 11.3 | 11.4 | 10.2 | 160.8 | 9.11 | 14.2 |
| 203 x 203 x 45 | 44.9 | 200.2 | 205.9 | 9.5 | 9.5 | 10.2 | 160.8 | 10.8 | 16.9 |
