square hollow section

Square Hollow Section (SHS)

Size
B x B		 Thickness
T		 Mass
M		 Sectional Area
A		 Moment of Inertia
l		 Radius of Gyration
i		 Elastic Modulus Wel Plastic Modulus
Wpl		 Torsional Constants Superficial Area per m
It Ct
mm mm kg/m cm2 cm4 cm cm3 cm3 cm4 cm3 m2/m
40X40 2.5 2.89 3.68 8.54 1.52 4.27 5.14 13.6 6.22 0.154
3.0 3.4 4.34 9.78 1.50 4.89 5.97 15.7 7.10 0.152
3.2 3.61 4.60 10.20 1.49 5.11 6.28 16.5 7.42 0.152
4.0 4.39 5.59 11.80 1.45 5.91 7.44 19.5 8.54 0.150
4.9 5.20 6.62 13.20 1.41 6.62 8.55 22.2 9.51 0.147
5.0 5.28 6.73 13.40 1.41 6.68 8.66 22.5 9.60 0.147
50X50 2.5 3.68 4.68 17.50 1.93 6.99 8.29 27.5 10.20 0.194
3.0 4.35 5.54 20.20 1.91 8.08 9.70 32.1 11.80 0.192
3.2 4.62 5.88 21.20 1.90 8.49 10.20 33.8 12.40 0.192
4.0 5.64 7.19 25.00 1.86 9.99 12.30 40.4 14.50 0.190
4.9 6.74 8.58 28.50 1.82 11.40 14.30 46.9 16.50 0.187
5.0 6.85 8.73 28.90 1.82 11.60 14.50 47.6 16.70 0.187
6.0 7.99 10.20 32.00 1.77 12.80 16.50 53.6 18.40 0.184
6.3 8.31 10.60 32.80 1.76 13.10 17.00 55.2 18.80 0.184
60X60 3.0 5.29 6.74 36.2 2.32 12.10 14.30 56.9 17.7 0.232
3.2 5.62 7.16 38.2 2.31 12.70 15.20 60.2 18.6 0.232
4.0 6.90 8.79 38.2 2.27 15.10 18.30 72.5 22.0 0.230
4.9 58.28 10.5td> 52.5 2.23 17.50 21.60 85.1 25.4 0.227
5.0 8.42 10.7 53.3 2.23 17.80 21.90 86.4 25.7 0.227
6.0 9.87 12.6 59.9 2.18 20.00 25.10 98.6 1 28.8 0.225

Size
B x B		 Thickness
T		 Mass
M		 Sectional Area
A		 Moment of Inertia
l		 Radius of Gyration
i		 Elastic Modulus Wel Plastic Modulus
Wpl		 Torsional Constants Superficial Area per m
It Ct
mm mm kg/m cm2 cm4 cm cm3 cm3 cm4 cm3 m2/m
60x60 6.3 10.3 13.1 61.6 2.17 20.50 26.0/td> 102 29.6 0.224
8.0 12.5 16.0 69.7 & 23.20 30.4 118 33.4 0.219
70x70 3.0 6.24 7.94 59.0 2.73 16.90 19.9 92.2 24.8 0.272
3.2 6.63 8.44 62.3 2.72 17.80 21.0 97.6 26.1 0.272
3.6 7.40 9.42 68.6 2.70 19.60 23.3 108 28.7 0.271
4.0 8.15 10.4 74.7 2.68 21.30 25.5 118 231.2 0.270
4.9 9.81 12.5 87.2 2.64 24.90 30.3 140 36.2 0.267
5.0 9.99 12.7 88.5 2.64 25.30 30.8 142 36.8 0.267
6.0 11.8 15.0 101.0 2.59 28.70 35.5 163 41.6 0.265
6.3 12.3 15.6 104.0 2.58 29.70 36.9 169 42.9 0.264
7.1 13.6 17.3 112.0 2.54 29.70 40.3 185 46.1 0.262
8.0 15.0 19.2 120.0 2.50 34.20 43.8 200 49.2 0.259
76.2x76.2 3.2 7.25 9.23 81.5 2.97 21.40 25.2 127 31.4 0.297
3.6 8.10 10.3 89.9 2.95 23.60 27.9 141 34.6 0.296
4.0 8.93 11.4 98.0 2.93 25.70 30.6 154 37.6 0.294
4.9 10.8 13.7 115.0 2.89 30.20 36.4 183 43.9 0.292
5.0 11.0 14.0 117.0 2.89 30.60 37.0 186 44.6 0.292
6.0 12.9 16.5 133.0 2.85 35.00 42.9 215 50.7 0.289
6.3 13.5 17.2 138.0 2.83 36.20 44.6 223 52.4 0.289
7.1 15.0 19.1 149.0 2.80 39.10 48.8 244 56.6 0.287
8.0 16.6 21.1 160.0 2.75 42.10 53.2 265 60.7 0.284

Size
B x B		 Thickness
T		 Mass
M		 Sectional Area
A		 Moment of Inertia
l		 Radius of Gyration
i		 Elastic Modulus Wel Plastic Modulus
Wpl		 Torsional Constants Superficial Area per m
It Ct
mm mm kg/m cm2 cm4 cm cm3 cm3 cm4 cm3 m2/m
150x150 8.8 38.4 48.9 1608 5.74 214 257 2549 313 0.577
10.0 43.1 54.9 1773 5.68 236 286 2832 344 0.574
12.0 50.8 64.7 2023 5.59 270 331 3272 391 0.569
12.5 52.7 67.1 2080 5.57 277 342 3375 402 0.568
16.0 65.2 83.0 2430 5.41 324 411 4026 467 0.559
160x160 5.0 24.1 30.7 1225 6.31 153 178 1892 226 0.627
5.6 26.9 34.2 1353 6.29 169 198 2098 249 0.626
6.0 28.7 36.6 1437 6.27 180 210 2233 264 0.625
6.3 30.1 38.3 1499 6.26 187 220 2333 275 0.624
7.1 33.7 42.9 1659 6.22 207 245 2595 304 0.622
8.0 37.6 48.0 1831 6.18 229 272 2880 335 0.619
8.8 41.1 52.4 1978 6.14 247 295 3125 361 0.617
10.0 46.3 58.9 2186 6.09 273 329 3478 398 0.614
12.0 54.6 69.5 2502 6.00 313 382 4028 454 0.609
12.5 56.6 72.1 2576 5.98 322 395 4158 467 0.608
14.2 63.3 80.7 2809 5.90 351 436 4579 508 0.603
16.0 70.2 89.4 3028 5.82 379 476 4988 546 0.599

Size
B x B		 Thickness
T		 Mass
M		 Sectional Area
A		 Moment of Inertia
l		 Radius of Gyration
i		 Elastic Modulus Wel Plastic Modulus
Wpl		 Torsional Constants Superficial Area per m
It Ct
mm mm kg/m cm2 cm4 cm cm3 cm3 cm4 cm3 m2/m
180x180 5.0 27.3 34.7 1765 7.13 196 227 2718 290 0.707
5.6 30.4 38.7 1954 7.10 217 252 3018 320 0.706
6.0 32.5 41.4 2077 7.09 231 269 3215 340 0.705
6.3 34.0 43.3 2168 7.07 241 281 3361 355 0.704
7.1 38.1 48.6 2404 7.04 267 314 3744 393 0.702
8.0 42.7 54.4 2661 7.00 296 349 4162 434 0.699
8.8 46.7 59.4 2880 6.96 320 379 4524 469 0.697
10.0 52.5 66.9 3193 6.91 355 424 5048 518 0.694
12.0 62.1 79.1 3677 6.82 409 494 5873 595 0.689
12.5 64.4 82.1 3790 6.80 421 511 6070 613 0.688
14.2 72.2 92.0 4154 6.72 462 566 6711 670 0.683
16.0 80.2 102 4504 6.64 500 621 7343 724 0.679
200x200 5.0 30.4 38.7 2445 7.95 245 283 3756 362 0.787
5.6 33.9 43.2 2710 7.92 271 314 4174 401 0.786
6.0 36.2 46.2 2883 7.90 288 335 4449 426 0.785
6.3 38.0 48.4 3011 7.89 301 350 4653 444 0.784
7.1 42.6 54.2 3345 7.85 335 391 5189 493 0.782
8.0 47.7 60.8 3709 7.81 371 436 5778 545 0.779

Size
B x B		 Thickness
T		 Mass
M		 Sectional Area
A		 Moment of Inertia
l		 Radius of Gyration
i		 Elastic Modulus Wel Plastic Modulus
Wpl		 Torsional Constants Superficial Area per m
It Ct
mm mm kg/m cm2 cm4 cm cm3 cm3 cm4 cm3 m2/m
200x200 8.8
52.2 66.5 4021 7.78 402 474 6288 590 0.777
10.0 58.8 74.9 4471 7.72 447 531 7031 655 0.774
12.0 69.6 88.7 5171 7.64 517 621 8208 754 0.769
12.5 72.3 92.1 5336 7.61 534 643 8491 778 0.768
14.2 81.1 103 5872 7.54 587 714 9417 854 0.763
16.0 90.3 115 6394 7.46 639 785 10340 927 0.759
250x250 5.0 38.3 48.7 4861 9.99 389 447 7430 577 0.987
5.6 42.7 54.4 5399 9.96 432 498 8271 640 0.986
6.0 45.7 58.2 5752 9.94 460 531 8825 681 0.985
6.3 47.9 61.0 6014 9.93 481 556 9238 712 0.984
7.1 53.7 68.4 6701 9.90 536 622 10325 792 0.982
8.0 60.3 76.8 7455 9.86 596 694 11525 880 0.979
8.8 66.0 84.1 8107 9.82 649 758 12572 955 0.977
10.0 74.5 94.9 9055 9.77 724 851 14106 1065 0.974
12.0 88.5 113 10556 9.68 844 1000 16567 1237 0.969
12.5 91.9 117 10915 9.66 873 1037 17164 1279 0.968
14.2 103 132 12094 9.58 967 1158 19139 1413 0.963
16.0 115 147 13267 9.50 1061 1280 21138 1546 0.959
