Dimensions : : BS 4-1: 1993 Tolerances : EN 10279 : 2000
| Designation | Mass per Metre | Depth of Section h |
Width of Section b |
Thickness | Distance of Cy | Radius | Depth Between Fillets d |
Ratios for Local Buckling | Second Moment of Area | |||
| Web S |
Flange t |
Root r1 |
Flange b/t |
Web d/s |
Axis x-x |
Axis y-y |
||||||
| kg/mtr | mm | mm | mm | mm | cm | mm | mm | cm4 | cm4 | |||
| 430 x 100 x 64 | 64.40 | 430 | 100 | 11 | 19 | 2.62 | 15 | 362 | 5.26 | 32.90 | 21940 | 722 |
| 380 x 100 x 54 | 54.00 | 380 | 100 | 9.50 | 17.5 | 2.79 | 15 | 315 | 5.71 | 33.20 | 15030 | 643 |
| 300 x 100 x 46 | 45.50 | 300 | 100 | 9 | 16.5 | 3.05 | 15 | 237 | 6.06 | 26.30 | 8229 | 568 |
| 300 x 90 x 41 | 41.40 | 300 | 90 | 9 | 15.5 | 2.60 | 12 | 245 | 5.81 | 27.20 | 7218 | 404 |
| 260 x 90 x 35 | 34.80 | 260 | 90 | 8 | 14.0 | 2.74 | 12 | 208 | 6.43 | 26.00 | 4728 | 353 |
| 260 x 75 x 28 | 27.60 | 260 | 75 | 7 | 12.0 | 2.10 | 12 | 212 | 6.25 | 30.30 | 3619 | 185 |
| 230 x 90 x 32 | 32.20 | 230 | 90 | 7.50 | 14.0 | 2.92 | 12 | 178 | 6.43 | 23.70 | 3518 | 334 |
| 230 x 75 x 26 | 25.70 | 230 | 75 | 6.50 | 12.5 | 2.30 | 12 | 181 | 6.00 | 27.80 | 2748 | 181 |
| 200 x 90 x 30 | 29.70 | 200 | 90 | 7 | 14.0 | 3.12 | 12 | 148 | 6.43 | 21.10 | 2523 | 314 |
| 200 x 75 x 23 | 23.40 | 200 | 75 | 6 | 12.5 | 2.48 | 12 | 151 | 6.00 | 25.20 | 1963 | 170 |
| 180 x 90 x 26 | 26.10 | 180 | 90 | 6.50 | 12.5 | 3.17 | 12 | 131 | 7.20 | 20.20 | 1817 | 277 |
| 180 x 75 x 20 | 20.30 | 180 | 75 | 6 | 10.5 | 2.41 | 12 | 135 | 7.14 | 22.50 | 1370 | 146 |
| 150 x 90 x 24 | 23.90 | 150 | 90 | 6.50 | 12.0 | 3.30 | 12 | 102 | 7.50 | 15.70 | 1162 | 253 |
| 150 x 75 x 18 | 17.90 | 150 | 75 | 5.50 | 10 | 2.58 | 12 | 106 | 7.50 | 19.30 | 861 | 131 |
| 125 x 65 x 15 | 14.80 | 125 | 65 | 5.50 | 9.50 | 2.25 | 12 | 82 | 6.84 | 14.90 | 483 | 80.00 |
| 100 x 50 x 10 | 10.20 | 100 | 50 | 5 | 8.50 | 1.73 | 9 | 65 | 5.88 | 13.00 | 208 | 32.30 |
Dimensions : BS 4-1 : 1993 Tolerances : EN 10279 : 2000
| Designation | Radius of Gyration | Elastic Modulus | Plastic modulus | Buckling Parameter U |
Torsional Index x |
Warping Constant H |
Torsional Constant J |
Area of Section A |
Mass per Metre | |||
| Axis x-x |
Axis y-y |
Axis x-x |
Axis y-y |
Axis x-x |
Axis y-y |
|||||||
| cm | cm | cm3 | cm3 | cm3 | cm3 | dm6 | cm4 | cm2 | kg/mtr | |||
| 430 x 100 x 64 | 16.3 | 2.97 | 1020 | 97.90 | 1222 | 176 | 0.917 | 22.50 | 0.219 | 63.00 | 82.10 | 64.40 |
| 380 x 100 x 54 | 14.8 | 3.06 | 791 | 89.20 | 933 | 161 | 0.932 | 21.20 | 0.150 | 45.70 | 68.70 | 54.00 |
| 300 x 100 x 46 | 11.9 | 3.13 | 549 | 81.70 | 641 | 148 | 0.944 | 17.00 | 0.0813 | 36.80 | 58.00 | 45.50 |
| 300 x 90 x 41 | 11.7 | 2.77 | 481 | 63.10 | 568 | 114 | 0.934 | 18.40 | 0.0581 | 28.80 | 52.70 | 41.40 |
| 260 x 90 x 35 | 10.30 | 2.82 | 364 | 56.30 | 425 | 102 | 0.942 | 17.20 | 0.0379 | 20.60 | 44.40 | 34.80 |
| 260 x 75 x 28 | 10.10 | 2.30 | 278 | 34.40 | 328 | 62.00 | 0.932 | 20.50 | 0.0203 | 11.70 | 35.10 | 27.60 |
| 230 x 90 x 32 | 9.27 | 2.86 | 306 | 55.00 | 355 | 98.90 | 0.950 | 15.10 | 0.0279 | 19.30 | 41.00 | 32.20 |
| 230 x 75 x 26 | 9.17 | 2.35 | 239 | 34.80 | 278 | 63.20 | 0.947 | 17.30 | 0.0153 | 11.80 | 32.70 | 25.70 |
| 200 x 90 x 30 | 8.16 | 2.88 | 252 | 53.40 | 291 | 94.50 | 0.954 | 12.90 | 0.0197 | 18.30 | 37.90 | 29.70 |
| 200 x 75 x 23 | 8.11 | 2.39 | 196 | 33.80 | 227 | 60.60 | 0.956 | 14.80 | 0.0107 | 11.10 | 29.90 | 23.40 |
| 180 x 90 x 26 | 7.40 | 2.89 | 202 | 47.40 | 232 | 83.50 | 0.949 | 12.80 | 0.0141 | 13.30 | 33.20 | 26.10 |
| 180 x 75 x 20 | 7.27 | 2.38 | 152 | 28.80 | 176 | 51.80 | 0.946 | 15.30 | 0.00754 | 7.34 | 25.90 | 20.30 |
| 150 x 90 x 24 | 6.18 | 2.89 | 155 | 44.40 | 179 | 76.90 | 0.936 | 10.80 | 0.00890 | 11.80 | 30.40 | 23.90 |
| 150 x 75 x 18 | 6.15 | 2.40 | 115 | 26.60 | 132 | 47.20 | 0.946 | 13.10 | 0.00467 | 6.10 | 22.80 | 17.90 |
| 125 x 65 x 15 | 5.07 | 2.06 | 77.30 | 18.80 | 89.90 | 33.20 | 0.942 | 11.10 | 0.00194 | 4.72 | 18.80 | 14.80 |
| 100 x 50 x 10 | 4.00 | 1.58 | 41.50 | 9.89 | 48.90 | 17.50 | 0.942 | 10.00 | 0.000491 | 2.53 | 13.00 | 10.20 |
