European Specification Beams with Parallel Flanges in Accordance with Euronorm 19-57
| Designation |
G |
h |
b |
tw |
tf |
r |
A |
hi |
d |
| kg/m |
mm |
mm |
mm |
mm |
mm |
cm2 |
mm |
mm |
| IPE 100 A |
6.89 |
98 |
55 |
3.6 |
4.7 |
7 |
8.78 |
88.6 |
74.6 |
| IPE 100 |
8.10 |
100 |
55 |
4.1 |
5.7 |
7 |
10.3 |
88.6 |
74.6 |
| IPE 120 A |
8.66 |
118 |
64 |
3.8 |
5.1 |
7 |
11.0 |
107.4 |
93.4 |
| IPE 120 |
10.4 |
120 |
64 |
4.4 |
6.3 |
7 |
13.2 |
107.4 |
93.4 |
| IPE 140 A |
10.5 |
138 |
73 |
3.8 |
5.6 |
7 |
13.4 |
126.2 |
112.2 |
| IPE 140 |
12.9 |
140 |
73 |
4.7 |
6.9 |
7 |
16.4 |
126.2 |
112.2 |
| IPE 140 R |
14.4 |
142 |
72 |
5.3 |
7.8 |
7 |
18.4 |
126.4 |
112.4 |
| IPE 160 A |
12.7 |
157 |
82 |
4.0 |
5.9 |
9 |
16.2 |
145.2 |
127.2 |
| IPE 160 |
15.8 |
160 |
82 |
5.0 |
7.4 |
9 |
20.1 |
145.2 |
127.2 |
| IPE 160 R |
17.7 |
162 |
81 |
5.6 |
8.5 |
9 |
22.6 |
145.0 |
127.0 |
| IPE 180 A |
15.4 |
177 |
91 |
4.3 |
6.5 |
9 |
19.6 |
164.0 |
146.0 |
| IPE 180 |
18.8 |
180 |
91 |
5.3 |
8.0 |
9 |
23.9 |
164.0 |
146.0 |
| IPE 180 O |
21.3 |
182 |
92 |
6.0 |
9.0 |
9 |
27.1 |
164.0 |
146.0 |
| IPE 180 R |
22.1 |
183 |
89 |
6.4 |
9.5 |
9 |
28.1 |
164.0 |
146.0 |
| IPE 200 A |
18.4 |
197 |
100 |
4.5 |
7.0 |
12 |
23.5 |
183.0 |
159.0 |
| IPE 200 |
22.4 |
200 |
100 |
5.6 |
8.5 |
12 |
28.5 |
183.0 |
159.0 |
| IPE 200 O |
25.1 |
202 |
102 |
6.2 |
9.5 |
12 |
32.0 |
183.0 |
159.0 |
| IPE 200 R |
26.6 |
204 |
98 |
6.6 |
10.5 |
12 |
33.9 |
183.0 |
159.0 |
| IPE 220 A |
22.2 |
217 |
110 |
5.0 |
7.7 |
12 |
28.3 |
201.6 |
177.6 |
| IPE 220 |
26.2 |
220 |
110 |
5.9 |
9.2 |
12 |
33.4 |
201.6 |
177.6 |
| IPE 220 O |
29.4 |
222 |
112 |
6.6 |
10.2 |
12 |
37.4 |
201.6 |
177.6 |
| IPE 220 R |
31.6 |
225 |
108 |
6.7 |
11.8 |
12 |
40.2 |
201.4 |
177.4 |
| IPE 240 A |
26.2 |
237 |
120 |
5.2 |
8.3 |
15 |
33.3 |
220.4 |
190.4 |
| IPE 240 |
30.7 |
240 |
120 |
6.2 |
9.8 |
15 |
39.1 |
220.4 |
190.4 |
| IPE 240 O |
34.3 |
242 |
122 |
7.0 |
10.8 |
15 |
43.7 |
220.4 |
190.4 |
| IPE 240 R |
37.3 |
245 |
118 |
7.5 |
12.3 |
15 |
47.5 |
220.4 |
190.4 |
Specification Beams with Parallel Flanges in Accordance with Euronorm 19-57
| Designation |
G |
h |
b |
tw |
tf |
r |
A |
hi |
d |
| kg/m |
mm |
mm |
mm |
mm |
mm |
cm2 |
mm |
mm |
| IPE 270 A |
30.7 |
267 |
135 |
5.5 |
8.7 |
15 |
39.1 |
249.6 |
219.6 |
| IPE 270 |
36.1 |
270 |
135 |
6.6 |
10.2 |
15 |
45.9 |
249.6 |
219.6 |
| IPE 270 O |
42.3 |
274 |
136 |
7.5 |
12.2 |
15 |
53.8 |
249.6 |
219.6 |
| IPE 270 R |
44.0 |
276 |
133 |
7.7 |
13.1 |
15 |
56.0 |
249.8 |
219.8 |
| IPE 300 A |
36.5 |
297 |
150 |
6.1 |
9.2 |
15 |
46.5 |
278.6 |
248.6 |
| IPE 300 |
42.2 |
300 |
150 |
7.1 |
10.7 |
15 |
53.8 |
278.6 |
248.6 |
| IPE 300 O |
49.3 |
304 |
152 |
8.0 |
12.7 |
15 |
62.8 |
278.6 |
248.6 |
| IPE 300 R |
51.7 |
306 |
147 |
8.5 |
13.7 |
15 |
65.9 |
278.6 |
248.6 |
| IPE 330 A |
43.0 |
327 |
160 |
6.5 |
10.0 |
18 |
54.7 |
307.0 |
271.0 |
| IPE 330 |
49.1 |
330 |
160 |
7.5 |
11.5 |
18 |
62.6 |
307.0 |
271.0 |
| IPE 330 O |
57.0 |
334 |
162 |
8.5 |
13.5 |
18 |
72.6 |
307.0 |
271.0 |
| IPE 330 R |
60.3 |
336 |
158 |
9.2 |
14.5 |
18 |
76.8 |
307.0 |
271.0 |
| IPE 360 A |
50.2 |
357.6 |
170 |
6.6 |
11.5 |
18 |
64.0 |
334.6 |
298.6 |
| IPE 360 |
57.1 |
360 |
170 |
8.0 |
12.7 |
18 |
72.7 |
334.6 |
298.6 |
| IPE 360 O |
66.0 |
364 |
172 |
9.2 |
14.7 |
18 |
84.1 |
334.6 |
298.6 |
| IPE 360 R |
70.3 |
366 |
158 |
9.9 |
16.0 |
18 |
89.6 |
334.6 |
298.6 |
| IPE 400 A |
57.4 |
397 |
180 |
7.0 |
12.0 |
21 |
73.1 |
373.0 |
331.0 |
| IPE 400 |
66.3 |
400 |
180 |
8.6 |
13.5 |
21 |
84.5 |
373.0 |
331.0 |
| IPE 400 O |
75.7 |
404 |
182 |
9.7 |
15.5 |
21 |
96.4 |
373.0 |
331.0 |
| IPE 400 R |
81.5 |
407 |
178 |
10.6 |
17.0 |
21 |
104 |
373.0 |
331.0 |
| IPE 400 V |
84.0 |
408 |
182 |
10.6 |
17.5 |
21 |
107 |
373.0 |
331.0 |
| IPE 450 A |
67.2 |
447 |
190 |
7.6 |
13.1 |
21 |
85.5 |
420.8 |
378.8 |
| IPE 450 |
77.6 |
450 |
190 |
9.4 |
14.6 |
21 |
98.8 |
420.8 |
378.8 |
| IPE 450 O |
92.4 |
456 |
192 |
11.0 |
17.6 |
21 |
118 |
420.8 |
378.8 |
| IPE 450 R |
95.2 |
458 |
188 |
11.3 |
18.6 |
21 |
121 |
420.8 |
378.8 |
| IPE 450 V |
104 |
460 |
194 |
12.4 |
19.6 |
21 |
132 |
420.8 |
378.8 |
European Specification Beams with Parallel Flanges in Accordance with Euronorm 19-57
| Designation |
G |
h |
b |
tw |
tf |
r |
A |
hi |
d |
| kg/m |
mm |
mm |
mm |
mm |
mm |
cm2 |
mm |
mm |
| IPE 500 A |
79.4 |
497 |
200 |
8.4 |
14.5 |
21 |
101 |
468.0 |
426.0 |
| IPE 500 |
90.7 |
500 |
200 |
10.2 |
16.0 |
21 |
116 |
468.0 |
426.0 |
| IPE 500 O |
107 |
506 |
202 |
12.0 |
19.0 |
21 |
137 |
468.0 |
426.0 |
| IPE 500 R |
111 |
508 |
198 |
12.6 |
20.0 |
21 |
142 |
468.0 |
426.0 |
| IPE 500 V |
129 |
514 |
204 |
14.2 |
23.0 |
21 |
164 |
468.0 |
426.0 |
| IPE 550 A |
92.1 |
547 |
210 |
9.0 |
15.7 |
24 |
117 |
515.6 |
467.6 |
| IPE 550 |
105 |
550 |
210 |
11.1 |
17.2 |
24 |
134 |
515.6 |
467.6 |
| IPE 550 O |
123 |
556 |
212 |
12.7 |
20.2 |
24 |
156 |
515.6 |
467.6 |
| IPE 550 R |
134 |
560 |
210 |
14.0 |
22.2 |
24 |
170 |
515.6 |
467.6 |
| IPE 550 V |
159 |
566 |
216 |
17.1 |
25.2 |
24 |
202 |
515.6 |
467.6 |
| IPE 600 A |
108 |
597 |
220 |
9.8 |
17.5 |
24 |
137 |
562.0 |
514.0 |
| IPE 600 |
122 |
600 |
220 |
12.0 |
19.0 |
24 |
156 |
562.0 |
514.0 |
| IPE 600 O |
154 |
610 |
224 |
15.0 |
24.0 |
24 |
197 |
562.0 |
514.0 |
| IPE 600 R |
144 |
608 |
218 |
14.0 |
23.0 |
24 |
184 |
562.0 |
514.0 |
| IPE 600 V |
184 |
618 |
228 |
18.0 |
28.0 |
24 |
234 |
562.0 |
514.0 |
| IPE 750 X 137 |
137 |
753 |
263 |
11.5 |
17.0 |
17 |
175 |
719.0 |
685.0 |
| IPE 750 X 147 |
147 |
753 |
265 |
13.2 |
17.0 |
17 |
187 |
719.0 |
685.0 |
| IPE 750 X 161 |
160 |
758 |
266 |
13.8 |
19.3 |
17 |
204 |
719.4 |
685.4 |
| IPE 750 X 173 |
173 |
762 |
267 |
14.4 |
21.6 |
17 |
221 |
719.8 |
685.8 |
| IPE 750 X 185 |
185 |
766 |
267 |
14.9 |
23.6 |
17 |
236 |
719.8 |
685.8 |
| IPE 750 X 196 |
196 |
770 |
268 |
15.6 |
25.4 |
17 |
251 |
719.2 |
685.2 |
| IPE 750 X 210 |
210 |
775 |
268 |
16.0 |
28.0 |
17 |
268 |
719.0 |
685.0 |
| IPE 750 X 222 |
222 |
778 |
269 |
17.0 |
29.5 |
17 |
283 |
719.0 |
685.0 |
